Lamp - Head
1230158
£354.00
Tax included
inc. VAT
£295.00 exc. VAT
UK VAT will be deducted at checkout for delivery outside the UK.
LED - Pair
Secure Online Ordering
All our pages are encrypted for your security
Worldwide Delivery
We ship nearly all the parts we supply worldwide!
12 Month Warranty
All parts covered by a 12 month warranty
Give your tractor headlamps a major upgrade with this LED headlamp insert kit. Designed for 5000, 6000, 7000, and 8000 Series Massey Ferguson tractors.
Beam Angle: Low Beam 20° / High Beam 24°
Cable length (mm): 150
CE Approved: Yes
Connection Type: H4 Connector
Dip: LH Dip
ECE Rating: Reg112 - E4 112R01/08*0571*00, Reg10 - E4 10R05/01*4199*00
Effective Lumens: 550 - 1670
Fixing: 3 Bolts
Function: 2, High / Low Beam
Housing Material: Aluminium
Interference EMC EMI CISPR 25: Class 3
IP Rating: IP6K9K
Lens Colour: Clear
Lens Material: Plastic Safety Glass
Light source: LED
Lumens Raw: 1560 - 2760
Lux Value: Low Beam 21000cd
Number of LEDs:: 2 LEDs
Overall height (mm): 140
Overall length (mm): 140
Overall width (mm): 88
Power Consumption @ 12V: Low Beam 1.33Amps
Related products: 151850,163905,163906
RH or LH Fitment: RH & LH
RoHS Approved: Yes
SAE Approved: No
Shape: Round
Volts: 10-30V
Watts: Low Beam 16W
With Noise Suppression: Yes
Working Temperature °C: -40°C to 50°C
Ø (mm): 140
Beam Angle: Low Beam 20° / High Beam 24°
Cable length (mm): 150
CE Approved: Yes
Connection Type: H4 Connector
Dip: LH Dip
ECE Rating: Reg112 - E4 112R01/08*0571*00, Reg10 - E4 10R05/01*4199*00
Effective Lumens: 550 - 1670
Fixing: 3 Bolts
Function: 2, High / Low Beam
Housing Material: Aluminium
Interference EMC EMI CISPR 25: Class 3
IP Rating: IP6K9K
Lens Colour: Clear
Lens Material: Plastic Safety Glass
Light source: LED
Lumens Raw: 1560 - 2760
Lux Value: Low Beam 21000cd
Number of LEDs:: 2 LEDs
Overall height (mm): 140
Overall length (mm): 140
Overall width (mm): 88
Power Consumption @ 12V: Low Beam 1.33Amps
Related products: 151850,163905,163906
RH or LH Fitment: RH & LH
RoHS Approved: Yes
SAE Approved: No
Shape: Round
Volts: 10-30V
Watts: Low Beam 16W
With Noise Suppression: Yes
Working Temperature °C: -40°C to 50°C
Ø (mm): 140
1230158
Specific References
-
Tractors < Massey Ferguson < 5400 < 5425
-
Tractors < Massey Ferguson < 5400 < 5435
-
Tractors < Massey Ferguson < 5400 < 5445
-
Tractors < Massey Ferguson < 5400 < 5455
-
Tractors < Massey Ferguson < 5400 < 5460
-
Tractors < Massey Ferguson < 5400 < 5460SA
-
Tractors < Massey Ferguson < 5400 < 5465
-
Tractors < Massey Ferguson < 5400 < 5470
-
Tractors < Massey Ferguson < 6400 < 6445
-
Tractors < Massey Ferguson < 6400 < 6455
-
Tractors < Massey Ferguson < 6400 < 6460
-
Tractors < Massey Ferguson < 6400 < 6465
-
Tractors < Massey Ferguson < 6400 < 6470
-
Tractors < Massey Ferguson < 6400 < 6475
-
Tractors < Massey Ferguson < 6400 < 6480
-
Tractors < Massey Ferguson < 6400 < 6485
-
Tractors < Massey Ferguson < 6400 < 6490
-
Tractors < Massey Ferguson < 6400 < 6495
-
Tractors < Massey Ferguson < 6400 < 6497
-
Tractors < Massey Ferguson < 7400 < 7465
-
Tractors < Massey Ferguson < 7400 < 7475
-
Tractors < Massey Ferguson < 7400 < 7480
-
Tractors < Massey Ferguson < 7400 < 7485
-
Tractors < Massey Ferguson < 7400 < 7490
-
Tractors < Massey Ferguson < 7400 < 7495
-
Tractors < Massey Ferguson < 8400 < 8450
-
Tractors < Massey Ferguson < 8400 < 8460
-
Tractors < Massey Ferguson < 8400 < 8470
-
Tractors < Massey Ferguson < 8400 < 8480
-
Tractor Sections < Electrical < Lighting
